Specifications
| Atomization | Air Cap No. | Tip size | Type | Pattern Range | Air consumption | Delivery |
|---|---|---|---|---|---|---|
| LVMP | DL6 | 0.5mm | G | Max. 80mm | 60L/min | 23mL/min |
| DL8 | 0.8mm | Max. 120mm | 80L/min | 51mL/min | ||
| 1.1mm | Max. 130mm | 77mL/min | ||||
| DR1 | 0.5/0.8/1.1 | Round | 20L/min | 23/51/77mL/min |
| Atomization | LVMP |
|---|---|
| Air Cap No. | DL6 |
| Tip size | 0.5mm |
| Type | G |
| Pattern Range | Max. 80mm |
| Air consumption | 60L/min |
| Delivery | 23mL/min |
| Atomization | LVMP |
|---|---|
| Air Cap No. | DL8 |
| Tip size | 0.8mm |
| Type | G |
| Pattern Range | Max. 120mm |
| Air consumption | 80L/min |
| Delivery | 51mL/min |
| Atomization | LVMP |
|---|---|
| Air Cap No. | DL8 |
| Tip size | 1.1mm |
| Type | G |
| Pattern Range | Max. 130mm |
| Air consumption | 80L/min |
| Delivery | 77mL/min |
| Atomization | LVMP |
|---|---|
| Air Cap No. | DR1 |
| Tip size | 0.5/0.8/1.1 |
| Type | G |
| Pattern Range | Round |
| Air consumption | 20L/min |
| Delivery | 23/51/77mL/min |
| Air inlet pressure | Weight | Air / Fluid inlet | Compressor |
|---|---|---|---|
| 0.1Mpa | 190g | G 1/4 | 0.75kW |
